Xcentric® High Performance Crusher Buckets are perfect for a wide range of different industries and applications. Xcentric Crusher Buckets are a type of high-performance excavator crusher equipment for crushing both wet and dry materials right on the jobsite. All of these excavator crushers are easy to use and can output crushed material in a variety of different sizes.
- Double the production of a conventional crusher bucket*
- Circular jaw movement allows for crushing of wet materials.
- New design prevents large pieces from getting stuck in the bucket´s mouth.
- Simple and fast output size adjustment.
- Minimal maintenance – grease every 50 hours of use.
- 14 models to fit 8 – 70 ton carriers
- Available Now! XC5F to fit Skid Steers
*vs. comparable models at max. particle size.
A Series Available Now
Since it’s introduction to the excavator crusher equipment market in 2014, Xcentric Ripper International has continued to develop the design of the double-shaft crushing bucket Xcentric Crusher, Now, with endless hours of development and countless experiences around the world, the “Series A” is available with several improvements over the previous models:
- Updated kinematics and jaw movement, achieving higher production rates and significantly less stagnation, requiring less power from the excavator.
More precise and simple granulometry adjustment system offers rapid change with a greater range of output sizes.
- The absence of a drain line in the hydraulic motors and the flow control valve make the equipment easily interchangeable between excavators, with a very low risk of failure in case of poor hydraulic adjustment.
- Maintenance-free power train increases the reliability of the machine in the long term.
- Made entirely of Hardox 400
Rental Return Crusher Buckets
Visit our Used Equipment page to see our current inventory.
15 Models
A model to fit every size machine
Crush On-Site
No transporting costs!
Easy to Operate
Simple output size adjustment
Got a question?
We’re here to help you pick out the best tool that suits your unique needs.
Accessories
Media Gallery
Photos














Video
View more videos
Specifications
Model | Weight (lbs) | Bucket Capacity (m3) | Oil Flow (gpm) | Operating Pressure (psi) | Output per hour (m3) | Carrier Weight (tons) |
---|---|---|---|---|---|---|
A Series | ||||||
XC5F | 3747 | 0.4 | 24 | 3480 | 4-70 | 4-6 Skid Steer |
XC8 | 2645 | 0.35 | 21 | 3625 | 3-70 | 8-11 |
XC9 | 3439 | 0.35 | 25 | 3625 | 4-70 | 10-13 |
XC13 | 3968 | 0.42 | 32 | 3625 | 8-74 | 13-16 |
XC19 | 4850 | 0.5 | 42 | 3625 | 10-77 | 16-21 |
XC21 | 5952 | 0.7 | 42 | 3625 | 10-77 | 20-25 |
XC24 | 8157 | 1.0 | 48 | 3625 | 19-87 | 24-33 |
XC 29 | 8818 | 1.2 | 53 | 3625 | 27-95 | 28-38 |
XC 34 | 12,125 | 1.5 | 61 | 3625 | 33-102 | 38-50 |
Regular Series | ||||||
XC15 | 4409 | 0.5 | 27-32 | 4641 | 5-70 | 13-15 |
XC17 | 4409 | 0.5 | 37-42 | 3625 | 7-75 | 16-20 |
XC20 | 5511 | 0.8 | 42-48 | 3625 | 10-77 | 20-25 |
XC30 | 8267 | 1.0 | 48-53 | 3625 | 19-87 | 24-35 |
XC40 | 11,685 | 1.2 | 79 | 4641 | 27-95 | 32-40 |
XC50 | 13,779 | 1.5 | 90 | 4641 | 33-102 | 38-55 |
XC60 | 18,740 | 2.0 | 100 | 4641 | 40-109 | 52-70 |
