Dipperfox Stump Crusher Excavator Attachments

The future of stump grinding is here! Design Masterclass 2020 award-winning Dipperfox Stump Grinder is available in Canada from ShearForce.

Dipperfox Stump Grinder is a brand-new stump grinder attachment for excavators. Its award-winning design makes work more efficient and a lot faster, saving you time and money.

The Dipperfox Stump Grinder drills through stumps and their roots, pushing all the remaining debris deep into the ground. There is no, therefore, need for additional clean-up on your logging and land clearing sites – once the work is finished, the sites are fully accessible for maintenance vehicles and provide ideal conditions for newly planted trees. No need to collect, transport, and utilize the remaining grinds – saving you, even more, time and resources.

Friend of the forest

This stump grinding attachment is easy on the soil. Its rotating blades crush and push all the wood residue into the ground and don’t leave any craters or voids behind. The site needs no additional equipment for cleanup and is ready for the planting of new trees.

Endurance is speed

Engineered, designed, and made in Estonia, Dipperfox aims to be a frontrunner in developing smart, easy-to-use, and efficient heavy equipment tools and accessories.

• Removes 2 to 3 stumps per minute – quick and efficient.
• Root system remains intact underground, offering added stability, especially in areas prone to erosion.
• Bolt-on blades and replaceable center screw and built-in hydraulic gearbox.
• 2 speeds – 60 RPM with 15,500 ft-lbs of torque and 30 RPM with 31,700 ft-lbs torque.
• No wiring involved  – simple hydraulic system with auto-shift.
• Suitable for large forested areas, steep slopes, or tight urban spaces.
• Patented one-of-a-kind-design.
• 3 models are available to fit skid steers, mini excavators, backhoes, and full-size machines.

Dipperfox Cone Splitter

The Dipperfox cone splitter is an attachment that turns the stump grinder into the world’s most effective cone splitter in just 15 minutes. All that is required is to take the bolt off the cutting tip and replace it with a splitting cone.

The cone splitters can be used with all the models and the main advantage, compared with other similar products in the market is the torque. The Dipperfox hydraulic engine provides the SC400 – 13 000N, SC600 – 17 000N and the SC850Pro – 43 000N. There are 4 parallel crests in the splitting cone with a massive 30 mm (1,2 “) thread pitch. This means that each revolve goes as deep as 150 mm/5,9” into the tree trunk. The tip of the cone splitter is made from Toolox 44 and is also replaceable.

Dipperfox 850 Pro Stump Grinder

Dipperfox Stump Grinder 850 PRO is a professional tool for 14-30t excavators. It is designed to work in urban and rural areas, in the forests, on roads, railways, and powerline construction areas. This revolutionary tool is making a significant difference in stump crushing efficiency. Thus, saving you time and money.

• 180 stumps in 1 hour – the fastest and most efficient drill on the market.
• Bolt-on blades are produced from extremely heavy-duty durable steel.
• Suitable for forest and urban challenges.
• Patented innovative technology.
• Easy PLUG & PLAY installment.
• State-of-the-art dynamic gearbox.
• Weight 575 kg.

Dipperfox 600 Stump Grinder

The Dipperfox product family is growing with the Dipperfox called 600. As the original Dipperfox 850 Pro is the most effective stump removal tool in the world for big excavators, for usage in construction and forestry. Our model 600, will carry on the performance, but it can be fitted for smaller carriers.

DF600 is a tool for those in cities, municipalities, arborists, and gardens – where full-size track excavators are too big to use. The main advantage compared with traditional stump grinders are safety, noise level, and efficiency. As the revolving speed of Dipperfox is max 60 RMP, there are no flying parts and in case the blade hits the rock, it will simply be pushed away. No need to create big safety zones for work. And as a true member of the Dipperfox family, the 600 does the same job but much quicker, compared with vertical grinders. Plus, it can be used to work below the ground, up to half a meter. It is very useful if you need to plant a new tree in the same place, where the original stump was located.

Dipperfox 600 is a multi-carrier tool that fits the following:

• Excavators between 6 to 14 tons.
• Backhoe Loader from 6 tons.
• Skid steer and compact track loaders from 6 tons.

Dipperfox 400 Stump Grinder- Model for Small Carriers

Dipperfox has added a new model –  The Dipperfox SC400 is designed to be used in populated places and tight spaces (Back yards, public parks, and urban areas). This compact model with a cutting diameter of 400mm (15.75”) can be used with various carriers like mini excavators, loaders, and mini or walk-behind skid steers. It also makes an excellent tool for landscapers, arborists, and other professionals.

• Its hydraulic engine produces a massive, 13 000 N of torque, providing plenty of power for low RPM cutting.
• There are no fast-moving blades to spread around the debris, leading to a smaller safety zone.
• All the debris stays near the drilling location making for easier cleanup.
• Reduced noise pollution compared to high-speed grinders.
• Allows stumps to be removed with speed, even where there is limited access (next to buildings, or surrounded by asphalt or rock).
